The next evolution
of digital substations
All-in-one intelligent grid automation solutions.
Engineered for performance, designed
for
flexibility and built for long-term reliability.
Desempenho
State-of-the-art protection and automation technology.
Fiabilidade
Engineered for continuous operation and long-term availability.
Inovação
Designed for IEC 61850 digital substations and future evolution.
One platform.
Multiple capabilities.
Engineered for performance, designed for flexibility and built for long-term reliability, ELYRA6 supports the complete lifecycle of power system assets, from engineering and configuration to operation and maintenance.
PROTECTION
Protection of infrastructure, and operational continuity.
AUTOMATION
Automation and intelligent execution of operations.
CONTROL
Management and operational control.
MONITORING
Real-time monitoring and analysis.
Explore the ELYRA6 documentation or speak with an Efacec specialist.
Built for today.
Ready for tomorrow.
Built for Efficiency & Reliability
Single platform reduces hardware variants and spare parts
- Simplified engineering, testing and maintenance
- Seamless legacy product configuration migration
- High availability and redundancy options
Designed for Flexibility
- Modular architecture adaptable to any application
- Expandable I/O and communication options
- Full IEC 61850 digital substation support
- Advanced custom logic using IEC 61131-3
Future-Ready Technology
- Continuous platform evolution and modular upgrades
- Proactive obsolescence management
- Cybersecurity compliance with applicable standards
- Web-based interface, no preventive maintenance required
Explore the ELYRA6 documentation or speak with an Efacec specialist.
Integrated functions
High-Performance Protection
Field-proven protection algorithms delivering sub-cycle tripping times, with built-in single-phase or three-phase tripping logic for a broad range of applications.
Advanced Control & Supervision
Synchronism-check, auto-reclosing and tap changer control, with select-before-operate and secure hardwired or distributed interlocking.
Enhanced Measurement & Monitoring
Accurate measurement of electrical quantities, power quality, condition monitoring, non-revenue metering and synchronized phasor measurements (PMU), all in one device.
Extended Recording & Fault Analysis
Large capacity recording of all power system fault data can be achieved through a flexible multi-source event recorder, full-featured disturbance records configured according to complex trigger options and stored in native COMTRADE format and a general-purpose statistical trend recorder. Enhanced fault summary is stored after each power system incident, summarizing relevant data for post-mortem analysis.
Digital Process Interface
Stand-alone merging unit (SAMU) per IEC 61850-9-2LE and IEC 61869-9, with fast GOOSE messaging and high-speed binary outputs for demanding protection applications.
Open automation
A complete engineering and automation ecosystem, from configuration tools to built-in cybersecurity and self-diagnostic capabilities.
Integrated Engineering
Automation Studio streamlines engineering, configuration and testing.
Distributed Automation
Rich IEC 61850 object model with advanced GOOSE and Sampled Values performance.
Programmable Logic
IEC 61131-3 programmable schemes integrated with built-in functions.
Device Platform
Modular hardware, scalable architecture and flexible configuration.
Advanced User Interface
Optional HMI and standards-compliant web interface.
Built-in Cybersecurity
Integrated firewall, RBAC, secure communications and audit capabilities.
Self-Diagnostics
Continuous supervision, diagnostics and optional redundant power and communication modules.
Explore the ELYRA6 documentation or speak with an Efacec specialist.
From transmission to industry
ELYRA6 supports new and retrofit projects across transmission and distribution networks, adapting to conventional, hybrid and fully digital substations.
TransmissionMotor ProtectionDistributionBay ControlTransformer ProtectionRTUDistance ProtectionMerging UnitDifferential ProtectionRenewablesVoltage ControlIndustrial Applications
Documentation
Explore the ELYRA6 technical documentation.
Engineered for continuity.
Designed for easy configuration.
Built for reliable
operation.
